Stock #: Q11844
Brand: OKUMA
Model: V100R
Type: Lathes, CNC
Condition: Excellent
Year: 2017
Okuma OSP-P200L CNC Control, 36" Power Chuck with C Axis, 12 Position Tool Turret with Live Tooling Option, Power Door, Work Light, Coolant System and Chip Conveyor. Only 3100 Cutting Hours. New 2017. Excellent Condition.
New Cost ( as equipped ) $ 472,000.
Specifications: |
|
|---|---|
| CNC Control | yes |
| Type of CNC Control | OSP-P200L CNC Control |
| Max Swing Over Bed | 49.21" |
| Max Turning Diameter | 39.37" |
| Chuck Size | 36" |
| Max Turning Height | 35" |
| Max Part Weight | 2,640 LBS |
| X-Axis (Cross Travel) | 22.24" of the turret |
| Z-Axis (Longitudinal Travel) | 35.04" of the turret |
| X-Axis Rapid Traverse Rate | 945 IPM |
| Z-Axis Rapid Traverse Rate | 945 IPM |
| Spindle Center Height From Floor | 46.1" |
| # Tool Turrets | 1 |
| Tool Turret Positions | 12 Total with Live Tooling |
| Spindle Speed Range | 13 - 750 RPM |
| Spindle Horsepower | 60 HP |
| Machine Cutting Hours | 3181 |
| Electrics | 220/480 / 3 / 60 |
| Approximate Machine Dimensions | 108" x 140" |
| Approximate Machine Height | 135" |
| Approximate Machine Weight | 30,000 LBS |
CONDITION: This Machine Appears to be in Excellent Condition !
