FANUC SERVO AMPLIFIER MODULE A06B-6096-H207

Stock #: Q11671

Brand: FANUC
Model: A06B-6096-H207
Type: Servo Drives
Condition: Excellent
Year: Not Specified

Equipped With:


Servo Amplifier Module SVM2-40/80/ FSSB Interface Alpha


Specifications:

Type Servo Amplifier Module
Function Axis Control
Discontinued by Manufacturer? yes
# Axis 2
Rated Input 283 - 325 VDC (8.5 kW)
Max Output Voltage 230 VAC
L-Axis Rated Output Current 12.5 A
M-Axis Rated Output Current 18.7 A
Manual No B-65162
Standards EN50178, UL508C
CNC? yes
Approximate Dimensions 17" x 10"
Approximate Height 18"
Approximate Weight 17 LBS
CONDITION: This Module Appears to be in Excellent Condition.

FANUC SERVO AMPLIFIER MODULE A06B-6096-H207
