Stock #: Q10837
Brand: MARATHON
Model: LQE 56T17G26L W
Type: Motors, A.C.
Condition: Very Good
Year: Not Specified
Specifications: |
|
---|---|
AC Motor Type | TSE |
Motor Horsepower | 3/4 HP |
Actual Rated Input Voltage | 230/460 V |
Full Load Amps | 2.7/1.35 A |
Base Speed | 1725 RPM |
Frame | 56-7 |
AC Frequency Rating | 60 Hz |
Motor Phase | 3 Phase |
Service Factor | 1.0 |
Insulation Class | B (Max 130° C) |
Ambient and Time Rating | 40° C AMB-CONT |
Approximate Dimensions | 7" x 11" |
Approximate Height | 13" |
Approximate Weight | 39 LBS |
CONDITION: This Motor Appears to be in Very Good Condition.
