Stock #: B10041
Brand: SIEMENS
Model: 1FT5076-OAC01-1-Z
Type: Servo Motors
Condition: Used
Year: Not Specified
3-Phase Tacho, 1 FU1050-6MC, 20 V/kRPM, VDE 0530, ΔT = 100° C, PTC Thermistor 155° C, Z: G45 K83.
Use only with 6SC610 Drives
Specifications: |
|
|---|---|
| Current Type | AC |
| Torque (Stall) | 22 Nm |
| Amp (Stall) | 32.4 A |
| Voltage | 150 V wye |
| Max Speed | 3,000 RPM |
| Efficiency | IEC 71 |
| Insulation Class | F (Max 155° C / 311° F) |
| Enclosure Rating | IP 64 |
| Encoder | ROD 320.002 |
| Motor Mounting Code | IM B5 |




Fields marked with * are required.
This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Fields marked with * are required.
This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Equipped With |
|---|
|
3-Phase Tacho, 1 FU1050-6MC, 20 V/kRPM, VDE 0530, ΔT = 100° C, PTC Thermistor 155° C, Z: G45 K83.
Use only with 6SC610 Drives |
Specifications |
|
|---|---|
| Current Type | AC |
| Torque (Stall) | 22 Nm |
| Amp (Stall) | 32.4 A |
| Voltage | 150 V wye |
| Max Speed | 3,000 RPM |
| Efficiency | IEC 71 |
| Insulation Class | F (Max 155° C / 311° F) |
| Enclosure Rating | IP 64 |
| Encoder | ROD 320.002 |
| Motor Mounting Code | IM B5 |
