CINCINNATI 30V 5-AXIS CNC VERTICAL MACHINING CENTER

Stock #: K14605

Brand: CINCINNATI MILACRON
Model: 30V
Type: Machining Centers, Vertical, (5-Axis or More)
Condition: Excellent
Year: 1989

Equipped With:



CNC Control……………. Acramatic 950 CNC<br>


# Axis……………… 5<br>


Table-L............................. 130" <br>


Table-W............................. 60"<br>


Longitudinal Travel (X-Axis)...................... 144"<br>


Cross Travel (Y-Axis)............................. 60" <br>


Vertical Travel (Z-Axis).......................... 24"<br>


Spindle Head Tilt (A-Axis) (+/- 25 Deg)........... 50°<br>


Spindle Head Swivel (B-Axis) (+/- 25 Deg)......... 50°<br>


Right Angle Head Rotation (Manual Location)....... 360°<br>


Max Clearance Tabletop to Rail............... 43"<br>


Feed Rates, (X, Y, & Z Axis)...................... .1 to 200 in/min.<br>


Feed Rate (A & B Axis)............................ 0 to 240 Deg/Min<br>


Rapid Traverse Rate, (X, Y, & Z Axis)............. 200 IPM<br>


Spindle Power................................ 30 HP<br>


Spindle Speeds Range Main......................... 20 – 3,600 RPM<br>


Spindle Taper..................................... #50 <br>


Approximate Machine Weight........................ 95,000 LBS

Specifications:


CONDITION: This Machine Appears to be in Excellent Condition !!

CINCINNATI 30V 5-AXIS CNC VERTICAL MACHINING CENTER

CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.
  • CINCINNATI MILACRON 30V 5-Axis, Acramatic 950 CNC Control, X=144",Y=60",Z=24",A & B +/- 25 Degree, raised, 90 Degree Head Attachment, New 1990.

Share:

Print Details

Fields marked with * are required.

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Fields marked with * are required.


      This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

      Brand
      CINCINNATI MILACRON

      Model
      30V

      Type
      Machining Centers, Vertical, (5-Axis or More)

      Stock #
      K14605

      Condition
      Excellent

      Year
      1989

      Request a Quote Today!

      Get Started

      Equipped With
      CNC Control……………. Acramatic 950 CNC<br>
      # Axis……………… 5<br>
      Table-L............................. 130" <br>
      Table-W............................. 60"<br>
      Longitudinal Travel (X-Axis)...................... 144"<br>
      Cross Travel (Y-Axis)............................. 60" <br>
      Vertical Travel (Z-Axis).......................... 24"<br>
      Spindle Head Tilt (A-Axis) (+/- 25 Deg)........... 50°<br>
      Spindle Head Swivel (B-Axis) (+/- 25 Deg)......... 50°<br>
      Right Angle Head Rotation (Manual Location)....... 360°<br>
      Max Clearance Tabletop to Rail............... 43"<br>
      Feed Rates, (X, Y, & Z Axis)...................... .1 to 200 in/min.<br>
      Feed Rate (A & B Axis)............................ 0 to 240 Deg/Min<br>
      Rapid Traverse Rate, (X, Y, & Z Axis)............. 200 IPM<br>
      Spindle Power................................ 30 HP<br>
      Spindle Speeds Range Main......................... 20 – 3,600 RPM<br>
      Spindle Taper..................................... #50 <br>
      Approximate Machine Weight........................ 95,000 LBS

      Specifications
      CONDITION: This Machine Appears to be in Excellent Condition !!
