Stock #: K13850
Brand: CINCINNATI MILACRON
Model: FALCON 300-1000
Type: Lathes, CNC
Condition: Excellent
Year: 1997
Acramatic 2100 CNC Control (P.C. Based), 14" Color Monitor, Touch Screen Programming, Probe Interface, Spindle Load Meter, Ethernet with TCP/IP, Floppy Disk Drive, Realtime Enhanced Performance, Maximum Program Probe Cycles for Toolsetter, Fanuc 0 Program Translation, 3rd Party Software Capability, Full Key Board, 12" 3-Jaw Hydraulic Chuck, Toolsetter, 12 Position Tool Turret, Coolant System, Chip Conveyor.
Specifications: |
|
|---|---|
| CNC Control | yes |
| Type of CNC Control | Acramatic 2100 CNC Control |
| Max Swing Over Bed | 25.59" |
| Max Swing Over Carriage | 18.80" |
| Max Tailstock Position | 42.4" |
| Chuck Size | 12" |
| X-Axis (Cross Travel) | 10.4" |
| Z-Axis (Longitudinal Travel) | 40.15" |
| Feed Range (Infinitely Variable) | .1-200 IPM |
| Rapid Traverse Rate | 600 IPM |
| # Tool Turrets | 1 |
| Tool Turret Positions | 12 Total |
| Spindle Nose | A2-8 |
| Spindle Bore | 3.7" |
| Spindle Speed Range | 30 - 3,000 RPM |
| Spindle Horsepower | 30 HP |
| Electrics | 460/3/60 |
| Approximate Machine Dimensions | 163" x 83" |
| Approximate Machine Height | 77.8" |
| Approximate Machine Weight | 14,600 LBS |
CONDITION: This Machine Appears to be in Excellent Condition !
