Stock #: K14010
Brand: DIACRO
Model: 150-12
Type: Brakes, Press
Condition: Very Good
Year: 1978
Di-Acro Hydro-Mechanical Design give you the Stroke Control of a Hydraulic Machine plus the Rigid Arm Link of a Mechanical Press Brake. Motorized Ram Adjustment, Dual Speed Cycles, Jog, Stroke and Continuous Cycles, Central Lube System.
Specifications: |
|
---|---|
Hyd/Mech | hydraulic |
Overall Length of Die Surface | 144" (12') |
Max Bending Length | 144" (12') |
Distance Between Housings | 126" (10'6") |
Tonnage Capacity | 150 Ton |
Throat Depth | 9.8" |
Shut Height w/o Bolster | 8" |
Length of Stroke (Adjustable) | 3" |
Ram Adjustment | 5" |
Shut Height Ram Up Stroke Down | 12" |
Electrics | 440/3/60 |
Approximate Machine Dimensions | 144" x 48" |
Approximate Machine Height | 115" |
Approximate Machine Weight | 23,800 LBS |
CONDITION: Machine Appears to be in Very Good Condition.
