SIEMENS SERVO MOTOR 1FT5102-0AC012-Z

Stock #: K15797

Brand: SIEMENS
Model: 1FT5102-0AC012-Z
Type: Servo Motors
Condition: Used
Year: Not Specified

Equipped With:


Permanent Magnet Motor
1-1/4″ Shaft Diameter
3-Phase Tacho
1 FU1050-6MC
20.0  V/KRPM

NOTE: Use Only with 6SC610 Drives

Specifications:

Torque (Stall) 33 Nm
Amp (Stall) 52.0 A
Voltage 144 V
Max Speed 2,000 RPM
Motor Phase 3-Phase
Insulation Class F (Max 155° C / 311° F)
Enclosure Rating IP 67
Motor Mounting Code IM B5
Discontinued by Manufacturer? yes
Approximate Dimensions 17" x 11"
Approximate Height 8"
Approximate Weight 71 LBS

SIEMENS SERVO MOTOR 1FT5102-0AC012-Z

Fields marked with * are required.

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Fields marked with * are required.


      This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

      Brand
      SIEMENS

      Model
      1FT5102-0AC012-Z

      Type
      Servo Motors

      Stock #
      K15797

      Condition
      Used

      Year

      Request a Quote Today!

      Get Started

      Equipped With

      Permanent Magnet Motor
      1-1/4″ Shaft Diameter
      3-Phase Tacho
      1 FU1050-6MC
      20.0  V/KRPM

      NOTE: Use Only with 6SC610 Drives

      Specifications

      Torque (Stall) 33 Nm
      Amp (Stall) 52.0 A
      Voltage 144 V
      Max Speed 2,000 RPM
      Motor Phase 3-Phase
      Insulation Class F (Max 155° C / 311° F)
      Enclosure Rating IP 67
      Motor Mounting Code IM B5
      Discontinued by Manufacturer? yes
      Approximate Dimensions 17" x 11"
      Approximate Height 8"
      Approximate Weight 71 LBS
